Buxco^® FinePointe Resistance and Compliance

RC Derived Parameters

• View List of RC Derived Parameters

  Parameter	Description	Units	Ventilated	Static
  F	Frequency - The instantaneous, breath-by-breath rate of breathing	BPM	X	X
  TV	Tidal Volume - The inspired volume of air per breath. The integral of the negative section of the flow curve	mL	X	X
  MV	Minute Volume - The product of the tidal volume and the respiratory rate, calculated on a breath-by-breath basis	mL/min	X	X
  RI	The Resistance to air moving in and out of the lung	cmH2O*secs/mL	X	X
  Cdyn	The dynamic compliance of the lung	mL/cm H2O	X	X
  Cstatic	The static compliance of the lung	mL/cm H2O		X
  dPpl	The maximum pressure deflection from the start of the breath during inspiration	cm H2O	X
  dPmax	The maximum pressure deflection over one breath	cm H2O	X
  EEW	End Expiration Work - Work of breathing. The integral of the pressure times flow dt (over the entire breath)	cm H2O*mL	X	X
  PIF	The maximum inspiratory flow that occurs in one breath	mL/sec	X	X
  PEF	The maximum expiratory flow that occurs in one breath	mL/sec	X	X
  Ti	The time spent inhaling during each breath, from the start of inspiration to the end of inspiration (determined by interpolation of start of expiration). The time flow is negative	Sec	X	X
  Te	The time spent exhaling during each breath, from start of expiration to end of expiration (determined by interpolation back to zero). The time flow is positive	Sec	X	X
  Ve	Expired Volume	mL	X
  R2	A value between 0 and 1 indicating how well the data fits the assumed model	N/A	X	X
  Rinx	Rejection Index - Calculates the percentage of breaths rejected	%	X	X
  EIW	End Inspiratory Work	cm H2O*mL
  E	Elastance	cm H2O/mL		X
  PEEP	Positive End Expiratory Pressure	cm H2O		X
  Plateau	Pressure measured during an inspiratory pause	cm H2O		X
  HR	Heart rate (when ECG or BP is connected)	mmHg	X	X
  MBP	Mean blood pressure (when BP is connected)		X	X
  SBP	Systolic blood pressure (when BP is connected)	mmHg	X	X
  DBP	Diastolic blood pressure (when BP is connected)	mmHg	X	X
